New Monday 42a
Happy Monday -
Korneff Audio started on a Black Friday five years ago, with one plug-in, the original Pawn Shop Comp. Five years later, we’ve got nine, and a bunch more waiting to see daylight. So, I guess happy birthday to us?
For this episode (producer/engineer John Agnello calls each of these an episode... sounds like an eventual podcast...), I thought I’d be extra useful by giving some info on our plug-ins, specifically going into how Dan and I use them in the studio, some design background, some usage hints.
There’s so much though, that I am splitting this into two emails, one today and one tomorrow. SO... keep an eye out for New Tuesday!
Factoids and Uses and Whatnot on All Our Plugins, going by age
Pawn Shop Comp/Pawn Shop Comp 2.0
It’s misnamed. It’s really a vintage channel strip consisting of a tube preamp coupled to a FET-style compressor. It works on everything, including the mix bus, but it’s el supremo on vocals and bass. Tons of saturation options because of the preamp, and the ability to switch in different tubes and transformers. The way we use the PSC is to put it on a channel, flip around to the backside, fiddle with the preamp and the tubes and transformer, and THEN adjust the compressor. Think of it as selecting the console you want to use before engaging the channel EQ.
Fun Factoid: The Operating Level control is a circuit Dan nicked off a cassette tape duplicator his Uncle Bob had given him when Dan was a wee teen. He liked how it sounded, so it wound up in the Pawn Shop Comp.
Usage Secret: I’ve mentioned this before... two of them, one right after the other, set one to respond quickly and the other a bit more slowly (play with attack and release). Swap the order in the inserts ’til you get something smooth.
Talkback Limiter
This beast is another FET-style limiter, based on a circuit found in SSL consoles designed to keep studio talkback mics from destroying speakers and ears. Hugh Padgham and Peter Gabriel invented gated drum sounds with this circuit.
Yes, it is amazing on drums. It makes anything snap and click and punch. It lives on our snares, kicks, room mics, etc. It’s probably the best overall drum compressor out there.
But, and I suppose it’s part of the FET transistor modeling, and the artifacts produced by an FET, the TBL adds a thickness to things. It’s hard to describe but I can hear it in my head. It has a similar sound to Neve Diode compressors. It makes me clench my jaw and want to bite something. If you know Neve compressors, you know what I’m talking about. Anyway, the TBL is really great on things like vocals and acoustic instruments provided you back the DRY WET BLEND way way down towards DRY. Like, barely crack it open. It adds a little beef and evenness. We typically follow it with another compressor.
Fun Factoid: for distortion effects, click around to the back and mess with the trimpots. AND for a real adventure, on the front panel, click on the power lights at the top and see what happens...
Amplified Instrument Processor
I wrote about this thing's monstrously good sounding EQ a few episodes ago. Further, I wrote a whole course on how to use it. If you want to be enrolled in the course, reply to this email and I’ll sign you into it.
Usage Idea: Put an AIP on each of your submix buses. Switch on the Proprietary Signal Processing button on the front, and then play around with the three different settings on the back - one is tube-ish, one is tape-ish, and one is California 1970s’ solid state-ish. Again, do this BEFORE you do anything else with the plug-ins. It’s like picking out different sounding channels for each grouping of instruments.
Micro Digital Reverberator
You know who likes reverb units with almost no controls? Me. I love messing around with compressors, and EQs, and delays but when I get to reverbs I just want presets that sound good. I don’t even like adjusting simple things, like the decay time. Maybe it’s from screwing around for hours on 480Ls and always going back to the presets. Who knows.
Do This: Even though the original hardware units this puppy is modeling were basically designed to go on an insert or across a whole mix, put the MDR on its own channel and feed it via a send. Why?
1) You want to be able to EQ your reverbs. This is a HUGE trick. This guy explains it better than I can, so go read this.
2) You want to be able to feed the output of one reverb unit into the next, and so on.
What?? Cascade the reverbs?? YES!!!! It’s total insanity and fun!
In fact, do this: Put THREE MDRs on three separate channels. One is a short small room, one is a plate, and the last is a huge concert hall. Use the small room to widen and add a touch of ambiance. Use the plate for vocals, but just a smidge, and then use the concert hall for pads, etc. NOW... feed a bit of that small room INTO the concert hall, but just a touch, to have some movement and depth way way back there in the speakers. For special moments, like the end of a solo, or a chunk of vocal line when the singer screams out his ex-wife’s name in anguish, or when someone has decided a certain single snare hit is incredibly important, feed the small room into the plate and the plate into the concert hall. Obviously automate this stuff.
Fun Factoid: Everyone overlooks this, but the MDR has stereo widening/narrowing on the back....
The Echoleffe Tape Delay
This is one intimidating monster. I’ve seen grown mix engineers fling themselves into oncoming traffic when they discover there are individual EQs, bias, and pan settings for each of the three delay lines. I have stood over their mangled bodies, finally at peace, and I’ve whispered, “Did you know you also have complete control over wow, flutter, tape age, head bump, as well as tape formulation, and you can switch off the Echoleffe’s delay function and just use it as a tape saturation simulator?"
This thing is the opposite of the MDR. It’s bristling with controls like a pissed-off German porcupine. It’s a pity, because once you get the logic of the controls, the ETD is quick to use and impossibly versatile. It can do easy things, like adding slapback on a vocal (it’s overkill for that, honestly), but it excels at making sounds you’ve never heard before.
The ETD can turn a single note into a keyboard pad that modulates and moves. It can twist delays into reverbs and musically sync the whole thing to the tempo of the track.
Usage Ideas: Set the delay times to below 11ms - set all three of them differently. Pan them everywhere. Play the track, and adjust the feedback for each delay line on the front panel, then go to the Tape Maintenance Panel and futz around with wow and flutter — this will add modulation to the delay times and suddenly you’ve got flanging happening that is out of this world and panned all over the stereo image. Gradually increase one of the delay times to get pitch-shifting effects. Automate the changes of the delay times. Play with the REVERB DENSITY switch on the front panel to basically DOUBLE the number of echo returns.
Even if you never buy this thing, download the demo and spend a week writing songs with it.
Licensing
Our original five plug-ins are iLOK-based for security purposes. Yes, we are phasing that out and soon our original five will use our own proprietary licensing system developed by Dan, the damn genius. When will this happen? We are hoping very very soon, but no promises. But know that we’ve heard your requests to get the heck off iLOK and we are working towards that.
I don’t have a new record this week. I’m still listening to Kim Deal every day. It gets better and more creative and insightful with each listen. But here’s a great interview with her on the Broken Record podcast. She talks about everything, including the new album. And she’s really really funny! And so so smart. She talks a lot about Steve Albini, and sadly, she occasionally refers to him in the present tense, as though he was still alive.
Warm regards,
Luke
